CPU
|
Intel® Socket 1150 for the New 4th/4th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Supports Intel® 22 nm CPU
Supports Intel® Turbo Boost Technology 2.0
|
|
Chipset
|
Intel® H81
|
|
Memory
|
4 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory *
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
|
|
Graphic
|
Integrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support : DVI/RGB ports
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 512 MB
Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
|
|
Expansion Slots
|
1 x PCIe 2.0 x16 (x16 mode, gray)
3 x PCIe 2.0 x1
3 x PCI
|
|
Storage
|
Intel® H81 chipset :
2 x SATA 6Gb/s port(s), gray
2 x SATA 3Gb/s port(s), black
Supports Intel® Rapid Start Technology, Intel® Smart Connect Technology
|
|
LAN
|
Intel®, 1 x Gigabit LAN Controller(s)
|
|
Audio
|
SupremeFX 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 115 dB SNR stereo playback output
Audio Feature :
- SupremeFX Shielding™ Technology
- ELNA premium audio capacitors
- Optical S/PDIF out port(s) at back panel
- Audio amplifier: Provides the highest-quality sound for headphone and speakers
|
|
USB Ports
|
Intel® H81 chipset :
2 x USB 3.0/2.0 port(s) (2 at back panel, blue)
Intel® H81 chipset :
8 x USB 2.0/1.1 port(s) (4 at back panel, )
ASMedia® ASM1042 controller :
2 x USB 3.0/2.0 port(s) (2 at mid-board)
|
|
Back I/O Ports
|
1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x DVI
1 x D-Sub
1 x LAN (RJ45) port(s)
2 x USB 3.0 (blue)
4 x USB 2.0
1 x Optical S/PDIF out
5 x Audio jack(s)
|
|
Form Factor
|
ATX Form Factor
12 inch x 8.4 inch ( 30.5 cm x 21.4 cm )
|
