Appearance
|
| Dimensions |
50.8 mm x 29.85 mm x 4.85 mm (2.00" x 1.18" x 0.19") |
|---|
| Weight |
9 g (0.32 oz) |
|---|
Interface
|
| Bus Interface |
|
|---|
Storage
|
| Flash Type |
|
|---|
| Capacity |
|
|---|
Operating Environment
|
| Operating Temperature |
0°C (32°F) ~ 70°C (158°F) |
|---|
| Operating Voltage |
|
|---|
Performance
|
| Sequential Read/Write (CrystalDiskMark) |
-
256 GB
530/400 MB/s
-
128 GB
550/400 MB/s
-
64 GB
390/200 MB/s
|
|---|
| 4K Random Read/Write (IOmeter) |
-
256 GB
45,000/70,000 IOPS
-
128 GB
55,000/70,000 IOPS
-
64 GB
35,000/50,000 IOPS
|
|---|
| Terabytes Written (TBW) |
-
256 GB
160 TBW
-
128 GB
80 TBW
-
64 GB
40 TBW
|
|---|
| Mean Time Between Failures (MTBF) |
1,000,000 hour(s) |
|---|
| Drive Writes Per Day (DWPD) |
0.5 (3 yrs) |
|---|
| Note |
- Speed may vary due to host hardware, software, usage, and storage capacity.
- The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
|
|---|
Warranty
|
| Certificate |
|
|---|
| Warranty |
- Three-year Limited Warranty
|
|---|
| Warranty Policy |
- Please click here for more information about the Transcend Warranty Policy.
- Warranty does not apply when SSD Scope's wear-out indicator displays 0% within the warranty coverage.
|
|---|
System Requirement
|
| Operating System |
- Microsoft Windows 7
- Microsoft Windows 8
- Microsoft Windows 10
- Linux Kernel 2.6.31 or later
|
|---|
